NGS 160kW VS Rotary Screw Compressor

Power: 160kW
Pressure: 8 / 10 / 13 Bar
Air Delivery: 460 L/s
Noise: 75 dB(A)
Request a quote

    REQUEST A QUOTE

    Talk to an Expert
    Model:
    NGS 160 VS
    Power:
    160kW
    Pressure Options:
    8 Bar / 10 Bar / 13 Bar
    Noise Level:
    75 dB(A)
    Dimensions:
    2700 x 1580 x 1770 mm
    Weight:
    ~3150 kg
    Free Air Delivery:
    460 L/s (8 Bar) / 410 L/s (10 Bar)
    Warranty:
    3 Years
    About the NGS 160 VS

    About the NGS 160 VS

    The Pilot Air NGS 160 VS is a 160 kW rotary screw compressor engineered for ultra-reliable, high-volume air delivery. Its direct-drive, two-stage compression design allows it to supply up to 460 L/s at 8 bar while maintaining impressive efficiency for its power class. This model is well-suited for large-scale manufacturing, processing plants, and facilities running multiple production lines or pneumatic systems. Like other NGS units, the NGS 160 VS comes equipped with an advanced electronic controller and variable-speed drive, which work together to optimise performance and energy use. Despite its size, it operates at a low noise level around 75 dB(A), and it offers optional remote monitoring for proactive maintenance.

    Key Features

    Key Features

    Built for Australian business and tested in the harshest conditions the NGS rotary screw range is backed by our platinum 3-year warranty and supported by onshore servicing, maintenance and an extensive inventory of spare parts. A workhorse that powers your business without the downtime.

    24/7 continuous duty performance

    Engineered for round-the-clock operation, the NGS 160 VS reliably handles continuous heavy air demand. Its industrial-grade design, featuring premium bearings and cooling components, enables it to operate continuously through multiple shifts without overheating or performance degradation.

    Heavy-duty industrial construction

    The compressor is built tough for demanding environments, featuring a robust frame and high-strength components. From its durable rotary screw air-end to the reinforced housing, every part of the NGS 160 VS is designed to withstand intensive use

    Advanced cooling system

    An efficient cooling system keeps the NGS 160 VS operating at optimal temperatures. A large oil cooler and thermostatically controlled fan work together to dissipate heat during compression, ensuring the compressor maintains peak performance and longevity.

    Multi-stage air filtration

    The NGS 160 VS utilises a multi-stage filtration process to safeguard the machine and your end-use applications. A heavy-duty intake filter captures contaminants from the incoming air, and a high-efficiency oil/air separator removes oil aerosol from the compressed air output.

    Programmable operation & scheduling

    The advanced controller on the NGS 160 VS allows you to program automatic start/stop schedules and operating modes. This means you can set the compressor to match your working hours or shift patterns.

    Backed by Pilot Air warranty & nationwide service

    The NGS 160 VS is backed by Pilot Air’s 3 year warranty, the highest in its class and supported by a nationwide network of qualified technicians and service specialists.

    Engineered air end

    The NGS 160 VS features an engineered rotary screw air-end that maximises airflow and efficiency. This air-end design minimises internal leakage and friction, ensuring consistent, high-volume air output with outstanding efficiency.

    MODEL SPECIFICATIONS

    Why Choose the Pilot NGS Range

    Pilot Air’s reputation for performance, reliability and service is unmatched in the Australian industrial market. The next generation (NGS) range is no exception. Engineered for users who need enhanced performance from a variable speed compressor but don’t require the advanced features of our premium models. It’s the sweet spot between affordability and performance.

    GET A QUOTE TODAY
    Performance

    Performance

    • Precision-engineered airend
    • High airflow outputs
    • Proven duty cycle
    Value

    Value

    • Competitive pricing
    • Lower lifetime cost
    • PM efficiency
    Reliability

    Reliability

    • Backed by Pilot Air warranty
    • National service support
    • Spare parts availability
    Service

    Service

    • Professional installation and servicing
    • Australia wide support
    • Rapid response

    Explore the Pilot NGS Rotary Screw Range

    Pilot Air’s next-generation rotary screw air compressors deliver on performance, reliability, and price. Constructed using premium components, the NGS variable speed compressors bridge the gap between our PAC fixed speed options and the premium ALTA TEC offering. The perfect balance of capability and value for money. Explore NGS Range.

    Need help choosing the right compressor?

    Pilot rotary screw compressors are the workhorses of Australian industry

    Model
    Air flow/Working Pressure
    Noise
    Motor
    Power
    Speed
    Starting Method
    Voltage/Frequency
    Protection Level/Insulation Level
    （L/S）/ BAR
    dB(A)
    kW
    rpm
    V/Hz
    NGS 7.5VS
    15 / 10
    62
    7.5
    2900
    Inverted
    415/50
    IP55, Grade F
    NGS 11VS
    21.67 / 10
    64
    11
    2930
    Inverted
    415/50
    IP55, Grade F
    NGS 15VS
    35 / 10
    64
    15
    2930
    Inverted
    415/50
    IP55, Grade F
    NGS 22VS
    53.33 / 10
    68
    22
    2950
    Inverted
    415/50
    IP55, Grade F
    NGS 37VS
    93.33 / 10
    68
    37
    2950
    Inverted
    415/50
    IP55, Grade F
    NGS 15VS-16Bar
    20 / 16
    72±2
    15
    2930
    Inverted
    415/50
    IP55, Grade F
    Download the Buying Guide Talk to a Specialist

    Ideal Applications for This Model

    Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat.

    Download the Pilot Air Rotary Screw Compressor Buying Guide

    Download the Pilot Air Rotary Screw Compressor Buying Guide

    We ensure the compressor system we supply is fit for purpose and future proofs your business. Download our buying guide or speak to our technical team about which NGS is the ideal solution for your needs.

    Get The Guide

    Downloads & Resources

    Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat.

    Spec Sheet PDF

    Spec Sheet PDF

    Download
    Range Brochure

    Range Brochure

    Download
    Warranty Summary

    Warranty Summary

    Download
    Buying Guide (PDF)

    Buying Guide (PDF)

    Download
    Technical Data Pack

    Technical Data Pack

    Download

    Ready to size the right compressor for your business?

    We offer expert advice, diagnostic assessment and onsite installation to ensure you have the right system and configuration for your site. Speak to one of our air specialists today.

    Request a Quote
    Pilot Air Service and Support

    Pilot Air Service and Support

    Our on-shore technical team are specialist in the design, installation, servicing and maintenance of your air compressor system. By auditing your site and using diagnostic data they provide a comprehensive solution that meets today’s demands and scales as you do.

We offer more than technical support. Our account managers are legendary relationship builders and our distributor network stretches from the coast to the interior. We are only ever a phone call away when you need us – we answer the call.

    System Design

    System Design

    We ensure the right compressor system for your requirements. From the compressor unit to the layout, piping, storage and treatment creating maximum performance and optimum efficiencies.

    Install & Commission

    Install & Commission

    Our technical team will install, test and commission your NGS rotary screw air compressor. For peace of mind and zero headaches, we leave nothing to chance.

    Maintenance & Spares

    Maintenance & Spares

    You won’t miss a beat with our comprehensive and onshore maintenance and spare parts division. We keep your compressed air system working as hard as you do.

    Technical Support

    Technical Support

    Pilot Air has a network of over 50 technical specialist across Australia. Wherever you are we have the reach and expertise to minimise downtime and keep your business moving.

    Frequently asked questions

    What type of facilities is the NGS 160kW VS designed for?

    The NGS 160kW VS is built for large-scale industrial operations with very high and continuous compressed air demands. It is ideally suited to manufacturing plants, processing facilities and sites running multiple production lines or complex pneumatic systems around the clock.

    How does the NGS 160 VS deliver high airflow while maintaining efficiency?

    With a direct-drive, two-stage compression design and variable-speed drive, the NGS 160 VS delivers up to 460 L/s at 8 bar while optimising energy use. The system adjusts output to match real-time demand, ensuring high efficiency even at this power level.

    Is the NGS 160 VS suitable for 24/7 continuous operation?

    Yes. The NGS 160 VS is engineered for continuous, heavy-duty operation. Premium bearings, robust internal components and industrial-grade cooling allow it to run reliably through multiple shifts without overheating or performance loss.

    How does the cooling and filtration system protect performance and air quality?

    An advanced cooling system, including a large oil cooler and thermostatically controlled fan, maintains stable operating temperatures. Multi-stage air filtration removes contaminants and minimises oil carryover, protecting both the compressor and downstream equipment.

    What control and scheduling features are available?

    The advanced electronic controller allows programmable start/stop scheduling and operating modes, enabling the compressor to align with shift patterns and working hours. Optional remote monitoring supports proactive maintenance and system optimisation.

    How does Pilot Air support long-term reliability and customisation?

    As an Australian company, Pilot Air backs the NGS 160 VS with a class-leading three-year warranty and nationwide service support. Our technical specialists can customise pressure configurations and system layouts to meet current requirements while future-proofing large industrial operations.
