NGS 185kW VS Rotary Screw Compressor

Power: 185kW
Pressure: 8 / 10 / 13 Bar
Air Delivery: 508.33 L/s
Noise: 76 dB(A)
Request a quote

    REQUEST A QUOTE

    Talk to an Expert
    Model:
    NGS 185 VS
    Power:
    185kW
    Pressure Options:
    8 Bar / 10 Bar / 13 Bar
    Noise Level:
    76 dB(A)
    Dimensions:
    2800 x 1830 x 2320 mm
    Weight:
    ~3450 kg
    Free Air Delivery:
    508.33 L/s (8 Bar) / 453.33 L/s (10 Bar)
    Warranty:
    3 Years
    About the NGS 185 VS

    About the NGS 185 VS

    The Pilot Air NGS 185 VS is a 185 kW heavy-duty rotary screw compressor delivering a massive volume of compressed air to keep the largest industrial operations running smoothly. This powerhouse is the ideal compressed air infrastructure, supporting continuous operation in big manufacturing plants, mining sites, or any facility with multiple high-demand air tools and machinery. Even at this high capacity, the NGS 185 VS retains the NGS advantages, such as two-stage compression and variable-speed efficiency, ensuring that energy costs remain in check. Its advanced controller, with remote monitoring capability, helps maintain reliability and uptime, while the rugged design enables 24/7 operation.

    Key Features

    Key Features

    Built for Australian business and tested in the harshest conditions the NGS rotary screw range is backed by our platinum 3-year warranty and supported by onshore servicing, maintenance and an extensive inventory of spare parts. A workhorse that powers your business without the downtime.

    High-capacity cooling & thermal protection

    The NGS 185 VS is equipped with a heavy-duty cooling system designed for larger industrial workloads. An oversized oil cooler and aftercooler, combined with a high-flow cooling fan, maintain safe operating temperatures even under continuous full-load operation.

    Remote monitoring & control

    This model features advanced connectivity for remote monitoring and management. Via an optional GSM/Ethernet module or similar interface, you can monitor real-time compressor performance, receive alerts, and adjust settings remotely.

    Comprehensive safety systems

    The NGS 185 VS features built-in protective measures to ensure safe operation. Sensors continuously monitor critical parameters such as temperature, pressure, and motor load, with the controller automatically unloading or shutting down the compressor if an abnormal condition occurs.

    Oversized aftercooler & moisture removal

    An integrated, high-efficiency aftercooler significantly drops the compressed air temperature, condensing and removing a large portion of moisture from the air stream.

    Industrial-scale air output

    With its formidable output capacity, the NGS 185 VS is built to supply compressed air for large-scale industrial operations. It can comfortably power extensive pneumatic systems or multiple production lines at once.

    Backed by Pilot Air warranty & nationwide service

    The NGS 185 VA is backed by Pilot Air’s 3 year warranty, the highest in its class and supported by a nationwide network of qualified technicians and service specialists.

    Premium IE4 motor & heavy-duty drive

    The compressor is driven by a super premium efficiency IE4-class permanent magnet motor, which provides exceptional performance with lower electrical consumption. This powerful motor, paired with a robust direct-drive transmission, ensures maximum uptime and efficiency.

    MODEL SPECIFICATIONS

    Why Choose the Pilot NGS Range

    Pilot Air’s reputation for performance, reliability and service is unmatched in the Australian industrial market. The next generation (NGS) range is no exception. Engineered for users who need enhanced performance from a variable speed compressor but don’t require the advanced features of our premium models. It’s the sweet spot between affordability and performance.

    GET A QUOTE TODAY
    Performance

    Performance

    • Precision-engineered airend
    • High airflow outputs
    • Proven duty cycle
    Value

    Value

    • Competitive pricing
    • Lower lifetime cost
    • PM efficiency
    Reliability

    Reliability

    • Backed by Pilot Air warranty
    • National service support
    • Spare parts availability
    Service

    Service

    • Professional installation and servicing
    • Australia wide support
    • Rapid response

    Explore the Pilot NGS Rotary Screw Range

    Pilot Air’s next-generation rotary screw air compressors deliver on performance, reliability, and price. Constructed using premium components, the NGS variable speed compressors bridge the gap between our PAC fixed speed options and the premium ALTA TEC offering. The perfect balance of capability and value for money. Explore NGS Range.

    Need help choosing the right compressor?

    Pilot rotary screw compressors are the workhorses of Australian industry

    Model
    Air flow/Working Pressure
    Noise
    Motor
    Power
    Speed
    Starting Method
    Voltage/Frequency
    Protection Level/Insulation Level
    （L/S）/ BAR
    dB(A)
    kW
    rpm
    V/Hz
    NGS 7.5VS
    15 / 10
    62
    7.5
    2900
    Inverted
    415/50
    IP55, Grade F
    NGS 11VS
    21.67 / 10
    64
    11
    2930
    Inverted
    415/50
    IP55, Grade F
    NGS 15VS
    35 / 10
    64
    15
    2930
    Inverted
    415/50
    IP55, Grade F
    NGS 22VS
    53.33 / 10
    68
    22
    2950
    Inverted
    415/50
    IP55, Grade F
    NGS 37VS
    93.33 / 10
    68
    37
    2950
    Inverted
    415/50
    IP55, Grade F
    NGS 15VS-16Bar
    20 / 16
    72±2
    15
    2930
    Inverted
    415/50
    IP55, Grade F
    Download the Buying Guide Talk to a Specialist

    Ideal Applications for This Model

    Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat.

    Download the Pilot Air Rotary Screw Compressor Buying Guide

    Download the Pilot Air Rotary Screw Compressor Buying Guide

    We ensure the compressor system we supply is fit for purpose and future proofs your business. Download our buying guide or speak to our technical team about which NGS is the ideal solution for your needs.

    Get The Guide

    Downloads & Resources

    Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat.

    Spec Sheet PDF

    Spec Sheet PDF

    Download
    Range Brochure

    Range Brochure

    Download
    Warranty Summary

    Warranty Summary

    Download
    Buying Guide (PDF)

    Buying Guide (PDF)

    Download
    Technical Data Pack

    Technical Data Pack

    Download

    Ready to size the right compressor for your business?

    We offer expert advice, diagnostic assessment and onsite installation to ensure you have the right system and configuration for your site. Speak to one of our air specialists today.

    Request a Quote
    Pilot Air Service and Support

    Pilot Air Service and Support

    Our on-shore technical team are specialist in the design, installation, servicing and maintenance of your air compressor system. By auditing your site and using diagnostic data they provide a comprehensive solution that meets today’s demands and scales as you do.

We offer more than technical support. Our account managers are legendary relationship builders and our distributor network stretches from the coast to the interior. We are only ever a phone call away when you need us – we answer the call.

    System Design

    System Design

    We ensure the right compressor system for your requirements. From the compressor unit to the layout, piping, storage and treatment creating maximum performance and optimum efficiencies.

    Install & Commission

    Install & Commission

    Our technical team will install, test and commission your NGS rotary screw air compressor. For peace of mind and zero headaches, we leave nothing to chance.

    Maintenance & Spares

    Maintenance & Spares

    You won’t miss a beat with our comprehensive and onshore maintenance and spare parts division. We keep your compressed air system working as hard as you do.

    Technical Support

    Technical Support

    Pilot Air has a network of over 50 technical specialist across Australia. Wherever you are we have the reach and expertise to minimise downtime and keep your business moving.

    Frequently asked questions

    What type of operations is the NGS 185kW VS designed for?

    The NGS 185kW VS is built for the largest and most demanding industrial operations. It is ideal for large manufacturing plants, mining sites, and facilities that run multiple high-demand pneumatic systems or production lines requiring a continuous, high-volume air supply.

    How does the NGS 185 VS control energy use at such high output levels?

    Despite its massive capacity, the NGS 185 VS uses variable-speed drive technology and two-stage compression to match output to real-time demand. This intelligent control helps keep energy consumption and operating costs in check compared to fixed-speed compressors of similar size.

    How does the cooling system support continuous heavy-duty operation?

    A heavy-duty cooling system, featuring an oversized oil cooler, aftercooler, and high-flow cooling fan, maintains safe operating temperatures even under full-load, 24/7 operation. This thermal protection is critical for reliability in harsh industrial environments.

    What monitoring and safety features are included?

    The advanced controller continuously monitors key parameters, including temperature, pressure, and motor load. Built-in safety systems automatically unload or shut down the compressor if abnormal conditions are detected, while optional remote monitoring allows real-time oversight and alerts.

    How does the aftercooler improve air quality and system performance?

    The oversized, high-efficiency aftercooler significantly reduces the temperature of compressed air and removes a substantial portion of moisture from the air stream. This helps protect downstream equipment and improves the overall reliability of the compressed air system.

    How does Pilot Air support large-scale customers using the NGS 185 VS?

    As an Australian company, Pilot Air backs the NGS 185 VS with a class-leading three-year warranty and nationwide service support. Our technical specialists work closely with customers to customise pressure configurations, optimise system design, and future-proof large industrial operations that require mission-critical compressed air.
