NGS 250kW VS Rotary Screw Compressor

Power: 250 kW
Pressure: 8 / 10 / 13 Bar
Air Delivery: 725 L/s
Noise: 76 dB(A)
Request a quote

    REQUEST A QUOTE

    Talk to an Expert
    Model:
    NGS 250 VS
    Power:
    250kW
    Pressure Options:
    8 Bar / 10 Bar / 13 Bar
    Noise Level:
    76 dB(A)
    Dimensions:
    3250 x 2130 x 2320 mm
    Weight:
    ~4250 kg
    Free Air Delivery:
    725 L/s (8 Bar) / 683.33 L/s (10 Bar)
    Warranty:
    3 Years
    About the NGS 250 VS

    About the NGS 250 VS

    The NGS 250 VS is the largest model in the NGS, packing 250 kW of power into a variable-speed rotary screw compressor for the highest-volume air demands. It’s capable of supplying entire factory operations or heavy industrial processes independently. This model is ideal for large-scale manufacturing plants and major mining or processing sites where maximum air throughput and reliability are paramount. Despite its immense output, the NGS 250 VS remains highly efficient; its two-stage compression and IE4 premium motor keep energy usage low for a compressor of this calibre. The advanced ‘Login’ controller with optional remote monitoring ensures 24/7 optimised performance and oversight, while the rugged build guarantees continuous duty under harsh conditions.

    Key Features

    Key Features

    Built for Australian business and tested in the harshest conditions the NGS rotary screw range is backed by our platinum 3-year warranty and supported by onshore servicing, maintenance and an extensive inventory of spare parts. A workhorse that powers your business without the downtime.

    Two-Stage ultimate efficiency compression

    The NGS 250 VS utilises a two-stage rotary screw compression design, delivering exceptional efficiency for a compressor of its size. This system reduces heat generation and energy loss, resulting in up to 20% energy savings.

    Master control for multi-unit sequencing

    When used in facilities with multiple compressors, the NGS 250 VS can serve as a master unit to coordinate a network of machines. Its advanced controller supports multi-compressor management, allowing it to intelligently sequence up to eight compressors in a master-slave arrangement.

    Flagship high-capacity output

    The NGS 250 VS offers the highest airflow capacity for the most demanding industrial needs. This unit is ideal as the primary air source for major manufacturing facilities, large-scale pneumatic systems, or entire industrial plants.

    Engineered for critical applications

    The NGS 220 VS features heavy-duty construction, including an ultra-rugged air-end, reinforced motor mountings, and high-quality electrical and cooling systems with built-in redundancies.

    Onboard analytics & diagnostics

    The advanced ‘Login’ electronic control system on the NGS 250 VS continuously monitors all aspects of the compressor’s performance. It provides real-time analytics and diagnostic information on pressures, temperatures, and component status.

    Backed by Pilot Air warranty & nationwide service

    The NGS 250 VA is backed by Pilot Air’s 3 year warranty, the highest in its class and supported by a nationwide network of qualified technicians and service specialists.

    Heat recovery option

    The NGS 250 VS offers an optional heat recovery system to further increase its industrial utility and efficiency. With this option, waste heat from the compression process can be captured and repurposed for use in your facility.

    MODEL SPECIFICATIONS

    Why Choose the Pilot NGS Range

    Pilot Air’s reputation for performance, reliability and service is unmatched in the Australian industrial market. The next generation (NGS) range is no exception. Engineered for users who need enhanced performance from a variable speed compressor but don’t require the advanced features of our premium models. It’s the sweet spot between affordability and performance.

    GET A QUOTE TODAY
    Performance

    Performance

    • Precision-engineered airend
    • High airflow outputs
    • Proven duty cycle
    Value

    Value

    • Competitive pricing
    • Lower lifetime cost
    • PM efficiency
    Reliability

    Reliability

    • Backed by Pilot Air warranty
    • National service support
    • Spare parts availability
    Service

    Service

    • Professional installation and servicing
    • Australia wide support
    • Rapid response

    Explore the Pilot NGS Rotary Screw Range

    Pilot Air’s next-generation rotary screw air compressors deliver on performance, reliability, and price. Constructed using premium components, the NGS variable speed compressors bridge the gap between our PAC fixed speed options and the premium ALTA TEC offering. The perfect balance of capability and value for money. Explore NGS Range.

    Need help choosing the right compressor?

    Pilot rotary screw compressors are the workhorses of Australian industry

    Model
    Air flow/Working Pressure
    Noise
    Motor
    Power
    Speed
    Starting Method
    Voltage/Frequency
    Protection Level/Insulation Level
    （L/S）/ BAR
    dB(A)
    kW
    rpm
    V/Hz
    NGS 7.5VS
    15 / 10
    62
    7.5
    2900
    Inverted
    415/50
    IP55, Grade F
    NGS 11VS
    21.67 / 10
    64
    11
    2930
    Inverted
    415/50
    IP55, Grade F
    NGS 15VS
    35 / 10
    64
    15
    2930
    Inverted
    415/50
    IP55, Grade F
    NGS 22VS
    53.33 / 10
    68
    22
    2950
    Inverted
    415/50
    IP55, Grade F
    NGS 37VS
    93.33 / 10
    68
    37
    2950
    Inverted
    415/50
    IP55, Grade F
    NGS 15VS-16Bar
    20 / 16
    72±2
    15
    2930
    Inverted
    415/50
    IP55, Grade F
    Download the Buying Guide Talk to a Specialist

    Ideal Applications for This Model

    Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat.

    Download the Pilot Air Rotary Screw Compressor Buying Guide

    Download the Pilot Air Rotary Screw Compressor Buying Guide

    We ensure the compressor system we supply is fit for purpose and future proofs your business. Download our buying guide or speak to our technical team about which NGS is the ideal solution for your needs.

    Get The Guide

    Downloads & Resources

    Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat.

    Spec Sheet PDF

    Spec Sheet PDF

    Download
    Range Brochure

    Range Brochure

    Download
    Warranty Summary

    Warranty Summary

    Download
    Buying Guide (PDF)

    Buying Guide (PDF)

    Download
    Technical Data Pack

    Technical Data Pack

    Download

    Ready to size the right compressor for your business?

    We offer expert advice, diagnostic assessment and onsite installation to ensure you have the right system and configuration for your site. Speak to one of our air specialists today.

    Request a Quote
    Pilot Air Service and Support

    Pilot Air Service and Support

    Our on-shore technical team are specialist in the design, installation, servicing and maintenance of your air compressor system. By auditing your site and using diagnostic data they provide a comprehensive solution that meets today’s demands and scales as you do.

We offer more than technical support. Our account managers are legendary relationship builders and our distributor network stretches from the coast to the interior. We are only ever a phone call away when you need us – we answer the call.

    System Design

    System Design

    We ensure the right compressor system for your requirements. From the compressor unit to the layout, piping, storage and treatment creating maximum performance and optimum efficiencies.

    Install & Commission

    Install & Commission

    Our technical team will install, test and commission your NGS rotary screw air compressor. For peace of mind and zero headaches, we leave nothing to chance.

    Maintenance & Spares

    Maintenance & Spares

    You won’t miss a beat with our comprehensive and onshore maintenance and spare parts division. We keep your compressed air system working as hard as you do.

    Technical Support

    Technical Support

    Pilot Air has a network of over 50 technical specialist across Australia. Wherever you are we have the reach and expertise to minimise downtime and keep your business moving.

    Frequently asked questions

    What type of operations is the NGS 250kW VS designed for?

    The NGS 250kW VS is engineered for the most demanding industrial environments. It is ideal for large-scale manufacturing plants, major mining operations and processing facilities that require an independent, ultra-high-volume compressed air supply to support entire factory operations.

    How does the NGS 250 VS maintain efficiency at such extreme output levels?

    Despite its 250 kW capacity, the NGS 250 VS remains highly efficient through its two-stage rotary screw compression and IE4 premium efficiency motor. This combination reduces heat generation and energy loss, delivering up to 20% energy savings compared to conventional single-stage compressors of similar size.

    Can the NGS 250 VS manage multi-compressor installations?

    Yes. The advanced Login controller allows the NGS 250 VS to operate as a master unit in a multi-compressor system. It can intelligently sequence and manage up to eight compressors in a master-slave arrangement, optimising system efficiency and balancing runtime across the fleet.

    What makes the NGS 250 VS suitable for critical, continuous-duty applications?

    The compressor features heavy-duty construction with an ultra-rugged air-end, reinforced motor mountings and high-quality electrical and cooling systems with built-in redundancies. This design ensures reliable, 24/7 operation in harsh industrial conditions where downtime is not an option.

    How does the control system support performance monitoring and maintenance?

    The advanced Login electronic controller continuously monitors pressures, temperatures and component status, providing real-time analytics and diagnostics. Optional remote monitoring enables proactive maintenance and improved oversight of critical compressed air infrastructure.

    How does Pilot Air support large-scale customers using the NGS 250 VS?

    As an Australian company, Pilot Air backs the NGS 250 VS with a class-leading three-year warranty and nationwide service support. Our technical specialists work closely with customers to customise system design, integrate heat recovery options and future-proof compressed air solutions for the largest industrial operations.
