NGS 90kW VS Rotary Screw Compressor

Power: 90kW
Pressure: 8 / 10 / 13 Bar
Air Delivery: 250 L/s
Noise: 72 dB(A)
Request a quote

    REQUEST A QUOTE

    Talk to an Expert
    Model:
    NGS 90 VS
    Power:
    90 kW
    Pressure Options:
    8 Bar / 10 Bar / 13 Bar
    Noise Level:
    72 dB(A)
    Dimensions:
    2100 x 1430 x 1740 mm
    Weight:
    ~1700 kg
    Free Air Delivery:
    250 L/s (8 Bar) / 230 L/s (10 Bar)
    Warranty:
    3 Years
    About the NGS 90 VS

    About the NGS 90 VS

    At the pinnacle of the standard NGS range, the NGS 90 VS delivers an impressive 90 kW (125 HP) of power, making it one of the most capable rotary screw compressors in Pilot Air’s NGS Series. With an output of roughly 250 L/s at 8 bar, the 90 VS is engineered for heavy-duty applications. It can supply compressed air for large-scale industrial complexes or serve high-demand processes with ease. Despite its formidable capacity, the 90 VS remains aligned with the NGS ethos: it is variable-speed driven for maximum efficiency, built with advanced twin-screw compression technology, and equipped with a state-of-the-art control and monitoring system. This model features Pilot Air’s latest two-stage compression setup, pushing the boundaries of what single-unit air compressors can achieve.

    Key Features

    Key Features

    Built for Australian business and tested in the harshest conditions the NGS rotary screw range is backed by our platinum 3-year warranty and supported by onshore servicing, maintenance and an extensive inventory of spare parts. A workhorse that powers your business without the downtime.

    Plant wide supply

    Delivering approximately 250 L/s at 8 bar, the NGS 90 VS provides the volume of compressed air required to support entire industrial facilities or extremely air-intensive processes. This makes it ideal as a central, base-load compressor in large-scale operations.

    Variable-speed drive delivers energy savings

    The integrated variable-speed drive continuously matches motor speed to real-time demand, eliminating inefficient full-load running during low-demand periods. Even as a 90kW unit, the

    Proven continuous-duty cycle

    A high-efficiency, industrial-grade motor coupled via a direct-drive configuration ensures minimal power loss and reduced mechanical wear. This design enhances reliability while maintaining smooth, consistent performance under heavy loads.

    Heavy-duty construction with exceptionally low noise

    A reinforced steel frame, advanced acoustic insulation, and vibration isolation allow the NGS 90 VS to operate at around 72 dB(A), remarkably quiet for its size.

    Comprehensive control, analytics, and industry 4.0 integration

    The advanced controller provides detailed operational analytics, including energy consumption, load profiles, and maintenance forecasting. Full compatibility with SCADA, BMS, and modern industrial communication protocols enables integration into smart manufacturing environments.

    Backed by Pilot Air warranty & nationwide service

    The NGS 90 VS is backed by Pilot Air’s 3 year warranty, the highest in its class and supported by a nationwide network of qualified technicians and service specialists.

    Engineered for reliability in Australian conditions

    Designed for continuous duty, the NGS 90 VS incorporates advanced cooling, extensive sensor monitoring, and layered protection systems to safeguard all critical components. These features ensure maximum uptime and predictable performance.

    MODEL SPECIFICATIONS

    Why Choose the Pilot NGS Range

    Pilot Air’s reputation for performance, reliability and service is unmatched in the Australian industrial market. The next generation (NGS) range is no exception. Engineered for users who need enhanced performance from a variable speed compressor but don’t require the advanced features of our premium models. It’s the sweet spot between affordability and performance.

    GET A QUOTE TODAY
    Performance

    Performance

    • Precision-engineered airend
    • High airflow outputs
    • Proven duty cycle
    Value

    Value

    • Competitive pricing
    • Lower lifetime cost
    • PM efficiency
    Reliability

    Reliability

    • Backed by Pilot Air warranty
    • National service support
    • Spare parts availability
    Service

    Service

    • Professional installation and servicing
    • Australia wide support
    • Rapid response

    Explore the Pilot NGS Rotary Screw Range

    Pilot Air’s next-generation rotary screw air compressors deliver on performance, reliability, and price. Constructed using premium components, the NGS variable speed compressors bridge the gap between our PAC fixed speed options and the premium ALTA TEC offering. The perfect balance of capability and value for money. Explore NGS Range.

    Need help choosing the right compressor?

    Pilot rotary screw compressors are the workhorses of Australian industry

    Model
    Air flow/Working Pressure
    Noise
    Motor
    Power
    Speed
    Starting Method
    Voltage/Frequency
    Protection Level/Insulation Level
    （L/S）/ BAR
    dB(A)
    kW
    rpm
    V/Hz
    NGS 7.5VS
    15 / 10
    62
    7.5
    2900
    Inverted
    415/50
    IP55, Grade F
    NGS 11VS
    21.67 / 10
    64
    11
    2930
    Inverted
    415/50
    IP55, Grade F
    NGS 15VS
    35 / 10
    64
    15
    2930
    Inverted
    415/50
    IP55, Grade F
    NGS 22VS
    53.33 / 10
    68
    22
    2950
    Inverted
    415/50
    IP55, Grade F
    NGS 37VS
    93.33 / 10
    68
    37
    2950
    Inverted
    415/50
    IP55, Grade F
    NGS 15VS-16Bar
    20 / 16
    72±2
    15
    2930
    Inverted
    415/50
    IP55, Grade F
    Download the Buying Guide Talk to a Specialist

    Ideal Applications for This Model

    Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat.

    Download the Pilot Air Rotary Screw Compressor Buying Guide

    Download the Pilot Air Rotary Screw Compressor Buying Guide

    We ensure the compressor system we supply is fit for purpose and future proofs your business. Download our buying guide or speak to our technical team about which NGS is the ideal solution for your needs.

    Get The Guide

    Downloads & Resources

    Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim ad minim veniam, quis nostrud exercitation ullamco laboris nisi ut aliquip ex ea commodo consequat.

    Spec Sheet PDF

    Spec Sheet PDF

    Download
    Range Brochure

    Range Brochure

    Download
    Warranty Summary

    Warranty Summary

    Download
    Buying Guide (PDF)

    Buying Guide (PDF)

    Download
    Technical Data Pack

    Technical Data Pack

    Download

    Ready to size the right compressor for your business?

    We offer expert advice, diagnostic assessment and onsite installation to ensure you have the right system and configuration for your site. Speak to one of our air specialists today.

    Request a Quote
    Pilot Air Service and Support

    Pilot Air Service and Support

    Our on-shore technical team are specialist in the design, installation, servicing and maintenance of your air compressor system. By auditing your site and using diagnostic data they provide a comprehensive solution that meets today’s demands and scales as you do.

We offer more than technical support. Our account managers are legendary relationship builders and our distributor network stretches from the coast to the interior. We are only ever a phone call away when you need us – we answer the call.

    System Design

    System Design

    We ensure the right compressor system for your requirements. From the compressor unit to the layout, piping, storage and treatment creating maximum performance and optimum efficiencies.

    Install & Commission

    Install & Commission

    Our technical team will install, test and commission your NGS rotary screw air compressor. For peace of mind and zero headaches, we leave nothing to chance.

    Maintenance & Spares

    Maintenance & Spares

    You won’t miss a beat with our comprehensive and onshore maintenance and spare parts division. We keep your compressed air system working as hard as you do.

    Technical Support

    Technical Support

    Pilot Air has a network of over 50 technical specialist across Australia. Wherever you are we have the reach and expertise to minimise downtime and keep your business moving.

    Frequently asked questions

    What types of applications is the NGS 90kW VS designed for?

    The NGS 90kW VS is engineered for large-scale industrial facilities and extremely air-intensive processes. With a flow rate of up to 250 L/s at 8 bar, it is ideal as a central, base-load compressor, supplying plant-wide air systems or supporting high-demand production environments.

    How does the NGS 90 VS achieve such high energy efficiency at its capacity?

    The integrated variable-speed drive continuously matches motor speed to real-time air demand, eliminating unnecessary full-load operation during periods of low demand. Even as a 90 kW unit, this intelligent control delivers substantial long-term energy savings compared to fixed-speed compressors.

    What makes the NGS 90 VS reliable for continuous, heavy-duty operation?

    The NGS 90 VS is designed for continuous duty, featuring heavy-duty construction, advanced cooling systems, and extensive sensor monitoring. Layered protection features safeguard critical components, ensuring maximum uptime and predictable performance in demanding Australian industrial conditions.

    How does the direct-drive and motor design improve performance and longevity?

    A premium-efficiency industrial motor coupled via a direct-drive system minimises power losses and mechanical wear. This design provides smooth, consistent performance under heavy loads while extending service life and reducing maintenance requirements.

    How does the control system support modern, connected industrial environments?

    The advanced controller delivers detailed operational analytics, including energy usage, load profiles, and maintenance forecasting. Full compatibility with SCADA, BMS and Industry 4.0 communication protocols allows seamless integration into smart manufacturing and automation systems.

    How does Pilot Air support customers using the NGS 90 VS?

    As an Australian company, Pilot Air backs the NGS 90 VS with a class-leading three-year warranty and nationwide service support. Our technical specialists work closely with customers to customise compressed air solutions, ensure reliable plant-wide performance and future-proof large industrial operations.
